Identify Mighty Mite pickup

  • Thread starter Thread starter Dodger
  • Start date Start date
D

Dodger

New member
Bought an old guitar with (according to te seller) "an old 70's pickup".
The zebra pickup is marked Mighty Mite, has a braided wire with three leads (black, White, and red) between the black and the white I read 13,5K and between the black and red I read 6,75K and between the red and black it's also 6,75K
Could that be a VH1300? and does anyone know which is + and - of black and white?


It's a 1300, to my ears as far as VH goes I believe he used the lower output 1400, the black is hot, white is ground, tape off the red

Stradazone":zl2ha8u2 said:
It's a 1300, to my ears as far as VH goes I believe he used the lower output 1400, the black is hot, white is ground, tape off the red

Thanks for that!
