New 2x12 for me..

[Ayrton]

Since I could not get what I wanted from Marshall, I made it...

I wanted a fixed baffle design like the Bogner, but slightly different dimensions. I still need to get with Jim about some speakers, and wrap the back.

The best part is everything but the plywood, I already had left over from all the 4x12 projects. The grill cloth is scrap I had from one of the '73 cabs.



[JakeAC5253]

Great work!



[jski59]

Nice job!



[The Hoff]

Impressed man. Good stuff

I'd pay for you to do work for me, so clean!



[XSSIVE]

excellent work as usual



[chobley]

That is a sweet cab ! Nice work . How long have you been building cabs?



[Ayrton]

That is a sweet cab ! Nice work . How long have you been building cabs?

Guitar specific, this is my first from scratch build. However, I have many a home/car speaker box.



[sinfish]

Great Job!

OK it is killing me. How did you cut perfect circles? Are them Rabbet joints? I really want to build my 2x12 vert slant. Just a little scared to mess things up.



[Ayrton]

Circle cutter...

https://www.amazon.com/Jasper-200J-Circl ... 166&sr=8-1

However, I jigsaw and a steady had will work just fine.

I wanted to do box joints, but my jig is not designed for something this size. I ended up using dowels and corner blocks. I have no doubt this method is actually stronger than fingers, but some things you just want to keep old school.



[droptrd]

Nice work. Very clean. Im building a pair of thiele cabs and they dont look as nice as yours



[droptrd]

Circle cutter...

https://www.amazon.com/Jasper-200J-Circl ... 166&sr=8-1

However, I jigsaw and a steady had will work just fine.

I wanted to do box joints, but my jig is not designed for something this size. I ended up using dowels and corner blocks. I have no doubt this method is actually stronger than fingers, but some things you just want to keep old school.

I cut my holes with my RotoZip.

My joints where just glue and nails



[tweed]

Nice!



[technomancer]

Wow great work, that looks fantastic



[Ayrton]

I cut my holes with my RotoZip.

My joints where just glue and nails

RotoZip works just fine, but I would caution against using metal fasteners if you plan to round over the edges.

You can get something like this

http://www.sears.com/shc/s/p_10153_1260 ... 967199000P

Or just pick up a bag of dowels for like $3 and drill without a jig.

Add some Titebond III, and that shit will never come apart.



[droptrd]

I cut my holes with my RotoZip.

My joints where just glue and nails

RotoZip works just fine, but I would caution against using metal fasteners if you plan to round over the edges.

You can get something like this

http://www.sears.com/shc/s/p_10153_1260 ... 967199000P

Or just pick up a bag of dowels for like $3 and drill without a jig.

Add some Titebond III, and that shit will never come apart.

Good point. I never thought of that. I dont have a router any way. I was just going to smooth the edges out with my palm sander. Heres my project - still not finished



[Ayrton]

That looks like it is coming along nicely!

I still have one more '70's 4x12 to finish up, and one more 2x12.

I don't know when I will get the next 2x12, I am about burnt out on the cab redos.



[jlbaxe]

From one wood worker to another…Awesome work!



[Meathead]

Very nice...I'd love to try something like that as a summer porject.
How did you cut so clean and steady the speaker holes in the baffle?
I think mine would look like a 104 sided stop sign.



[Ayrton]

How did you cut so clean and steady the speaker holes in the baffle?

A plunge router and Jasper jig are your friend.



[chobley]

Will the top fit a regular sized head ? I'm a big fan of the Bogner OS 2x12 , but this is
