Cornford gut pics : Help me out!!! Find me my bias pot.

  • Thread starter Thread starter GRK
  • Start date Start date
G

GRK

New member
Being a noob sucks ass... :doh:

Well at least you get to see Cornford MK guts eh?!



Can't really see from your pics, maybe the white thing with a black center? Just look for anything with a screwdriver slot in it, and that should be it. It might be standing upright, with a slot in the side, or a square with a slot on the top. I don't know. But it'll be the only thing on the board that you can stick a screwdriver in. (Most likely anyway)

Marshall Freak":47t9j50r said:
Can't really see from your pics, maybe the white thing with a black center? Just look for anything with a screwdriver slot in it, and that should be it. It might be standing upright, with a slot in the side, or a square with a slot on the top. I don't know. But it'll be the only thing on the board that you can stick a screwdriver in. (Most likely anyway)
Click to expand...
hmm there's actually something like that. i'll try adding more clear pics tomorrow. In the second pic, there's the round black thing next to the blue resistor or whatever. That's the only thing that looks like what you said.

Black with the white center is probably it. Near the bottom edge of the board in the bottom pic.

Loudness250":2tw5umx0 said:
Black with the white center is probably it. Near the bottom edge of the board in the bottom pic.
Click to expand...
Yeah I think so. It does have a slot where you can put a small screwdriver in. And I can't find anything else like it.

I was wondering cause I sort of expected it to be near tubes or something. But hey, I have no idea so there...

GRK":3ixmn2p7 said:
Loudness250":3ixmn2p7 said:
Black with the white center is probably it. Near the bottom edge of the board in the bottom pic.
Click to expand...
Yeah I think so. It does have a slot where you can put a small screwdriver in. And I can't find anything else like it.

I was wondering cause I sort of expected it to be near tubes or something. But hey, I have no idea so there...
Click to expand...

the diode and the resistor both right by that pot is generally a dead giveaway that is the bias pot. :) If you're still not sure.. you can follow pin 5 (the pin in between the white cement/wire resistor) on the power tube sockets to the board which will be hooked up to the negative and positive feedback which gets its voltage from the bias circuit.

Have no clue, just chiming in about the build......very nice :thumbsup:

Loudness250":3h2brgva said:
Black with the white center is probably it. Near the bottom edge of the board in the bottom pic.
Click to expand...

+1, that is your bias pot right there.

Cheers,
Mike

Thanks for all the replies guys!

Now I just gotta wait for my new tubes and bias tool :doh:
