I have a Wulffson Custom guitar that I'm changing a pickup in and need help on a wiring diagram. It is a hum/single setup with a 3 way toggle switch and what I suspect was supposed to be 1 vol 1 tone, but the tone knob never changed the sound one bit. So since they're both 500k pots and both really close to each other, I think I'll wire them up as dual volumes. One of the pots has an orange cap on it
The JB is a 4 conductor with white, green, black, and red. The red and white appear to be taped together and not used, the green goes to the body of the pot that was the volume and the black goes to one of the positions on the selector. The neck pickup is now a Duncan Quarter Pound with just the black and white wires.
The JB is a 4 conductor with white, green, black, and red. The red and white appear to be taped together and not used, the green goes to the body of the pot that was the volume and the black goes to one of the positions on the selector. The neck pickup is now a Duncan Quarter Pound with just the black and white wires.
