New JCM Modified Video: What's the Tight Switch do?

FourT6and2 said:
Nobody knows exactly what the tight switch does at this point. But it could be any number of things, as already mentioned. Switching out a cathode bypass cap, or switching some sort of voltage divider, or high-pass filter, or whatever. Either way, I'm pretty sure it's super simple and easy to implement. You'll just have to wait for someone to buy one and then post photos.
Click to expand...
I guess this doesn't help...

Tone Monster said:
FOURTEEN years ago? That would be minimum double these days.
Click to expand...
Around that time (maybe early 2010’s) I had asked Dave about the price of the kitchen sink mods and he had said 800$. (Not including shipping). Whether Dan got more done than that, I don’t know. Considering how good those Marshall’s were sounding back then it would have been money well spent.

skoora said:
Around that time (maybe early 2010’s) I had asked Dave about the price of the kitchen sink mods and he had said 800$. (Not including shipping). Whether Dan got more done than that, I don’t know. Considering how good those Marshall’s were sounding back then it would have been money well spent.
Click to expand...
Nice

Where the switch is located on the front panel might be a clue. They’re not putting anything NFB-related near the input jacks and they’re not switching a preamp cathode bypass cap down by the Presence.

SpiderWars said:
Where the switch is located on the front panel might be a clue. They’re not putting anything NFB-related near the input jacks and they’re not switching a preamp cathode bypass cap down by the Presence.
Click to expand...

Well there are no switches by the presence/NFB circuit. And the Tight switch is between the gain and master. So it's most likely either a coupling cap or cathode bypass cap. Neither are super secret mojo sauce "mods". As far which stage gets switched, if it's a coupler, I've had better results with 0.0022uF in the second stage, rather than the first.

FourT6and2 said:
Well there are no switches by the presence/NFB circuit. And the Tight switch is between the gain and master. So it's most likely either a coupling cap or cathode bypass cap. Neither are super secret mojo sauce "mods". As far which stage gets switched, if it's a coupler, I've had better results with 0.0022uF in the second stage, rather than the first.
Click to expand...
That sounds about right and I agree. And regarding the couplers I think a lot depends on the plate resistor. With typical loads a 330k plate is going to already limit bandwidth so a 2n2 coupler can get pretty nasally. Where a 100k plate and 22n has quite a lot of low end.

I was gassing pretty hard for the 1959HW Modified... but after seeing the preorder dates kept getting pushed back, I found a 1959HW and had a master volume and bright cap switch modded into it. I really dug the Andertons and TPS videos on it.
