Anubae_obscura":3ib8bgpw said:
OldSkoolNJ":3ib8bgpw said:
My Snott watt is all I play through these days
That amp is sick...care to give details?
I use my valvestate or pod x3 live w phones...im open for tone secrets on the pod
The face plate I did my self but the amp was made by Dave at
http://baroncustomamps.com/
It uses (3) 12AX7 preamp tubes and (1) 12BH7 tube in a Push/Pull AB1 configuration.
The amp has 2 gain Modes or channels Vintage and Modern.
The Vintage Mode will go from clean setting at low gain settings to crunch tones at high gain settings.
The Modern Mode is the high gain mode and will take you into very heavy tones at high gain settings.
Mode gain modes have separate Gain controls and Bright Switches.
The Modern gain mode has a “Wet/Dry” switch that effects how tight or open and saturated the gain is. The Dry setting is very tight with less gain and the Wet setting has +3dB more gain and is more saturated sounding.
The Amp has a global tone stack, Treble Mids and Bass and a Master Volume control.
There is a Brutal/Brown voltage switch on the front that changes the amps voltage by 70 volts to give you a warmer brown sound or a more focused tighter sound.
Speaker impedance selector 4,8,16 ohms.
Compensated Line out allows you to have the entire amp signal including power amp tone available at the Line out Jack. Also there is an internal dummy load when the speaker jack is unplugged so you can use the amp as a preamp into another amp or a direct recording interface.
The amp puts out about 6.5 to 7 watts in the higher voltage mode.
